Standard Dimensions*

Optional Turntable Capacities

Optional Process Stages

Optional Heating Methods

Turntable Diameter

Work Height

28"

36"

1,000 lbs.

First re-circulated stage (wash or pre-wash)

Electric

36"

48"

2,500 lbs.

Second re-circulated (wash or rinse)

Steam

42"

60"

6,000 lbs.

Third re-circulated stage (rinse)

Gas

62"

72"

10,000 lbs.

Fresh water rinse

75"

84"

20,000 lbs.

Blow-off

88"

96"

40,000 lbs.

Dryer

100"

108"

60,000 lbs.

Pump pressure to 1600 PSI

124"

120"

148"

144"

156"

* Other sizes and configurations are available.

Optional Features:

• 7 Day Timer
• Additional cycle timers
• Blow-off, heated regenerative
• Blow-off, plant air
• Blow-off, regenerative
• Center nozzle pipe (fixed or oscillating)
• Centrifuge solid removal
• Chemical concentration maintenance system
• Cycle finish signals (light and/or horn)
• Door, Power operation (with swing-out turntable only)
• Door, side access
• Doors, double hinged (with fixed turntable only)
• Doors, guillotine (with fixed turntable only)

• Exhaust blower
• Full flow bag-type filter
• High level alarm package
• Increased pump capacity
• J.I.C. wiring
• Level control, automatic
• Level control, proximity switch
• Load tray
• Loading boom
• Mirror image construction
• Oil coalescing unit
• Oil skimmer (belt or disc)
• Paint, other than standard
• Parts basket
• Parts rack
• Plastic coated turntable inserts
• Pressure / flow control valve and pressure gauge

• Programmable Logic Controller
• Proofing test
• Rust inhibiting, Venturi injector
• Sludge baffle
• Sludge removal & grease skim conveyor
• Sound enclosure
• Stainless steel construction
• Start-up assistance
• Swing-down manifold
• Tank pump-out package
• Temperature controller, digital
• Turntable alignment and stop
• Zero-discharge multi-stage filtration unit
